Corrugation Heaters
Corrugation heaters are heating elements with ridged surfaces, designed for efficient heat transfer and uniform heating of corrugated materials in applications such as packaging and manufacturing processes.
Kalka Engineers pioneered the launch of hi-tech tubular heaters for the Corrugation industry in the country. It is used to heat the rolls of the corrugation machine which in turn flute on the paper. These are specific models of heaters for different machine models. The heating element is easily replaceable and available in various dimensions and sizes. Our product ranges is fabricated using magnesium oxide and have technologically advanced features and assure quality as well as superior performance. The heater includes a curved metal plate where channels are drilled through end faces of the plate slots are provided at the end faces of the plate to interconnect pairs of adjacent channels at alternate ends to form a serpentine steam passage through the plate. These can also withstand high temperature owing to the use of superior grade raw material in their production. This Product is highly appreciated by the clients for its durability, corrosion resistant, reliability and long service life.
Standard features
- Tubes Available in 11 mm & 13.5 mm dia.
- Sheath material S.S 304 & INC 800.
- Available in 28’’, 32’’, 36’’, 42’’, 46’’, 52’’, 62’’, 72’’ oblique and vertical design also as per customer specification.
- Each heater consists of 9 nos heating rods in star connected for three phase supply.
- Each heater rod easily replaceable.
- These heaters are available in different ratings depending upon the size of machine.
- Electricity savings due to usage of precision wound resistance wire resulting in uniform heating.
- Higher durability and longevity due to stainless steel sheath material frame.
- Convenient installations operations.
- Each heating element is dully tested for capacity and electrical insulation.
- Powder coated connection box to prevent rusting and ensure safety.
FAQ
Got a Question?
1. Compressed heating elements for more effective and long-lasting heat transfer.
2. A heating coil made of kanthal or nichrome 80/20.
3. S.S. 304 heater tube sheath.
4. Electrical and good heat transfer are both facilitated by imported high-grade MgO powder insulation.
5. Stopping the fusing and burning of terminal pins made of stainless steel.
6. Rapid heating is cost-effective and power-saving.
7. The centre supporting rod for low- and high-power heaters is manufactured of M.S.
8. Reliable and efficient.
9. The ability to quickly and easily replace individual components.
1. Heating elements that have been compacted for improved heat transfer and durability.
2. A heating coil made of kanthal or nichrome 80/20.
3. S.S. 304 heater tube sheath.
4. High grade MgO powder insulation imported for the finest electrical and heat insulation.
5. Terminal pins made of stainless steel to prevent burning and fusing.
6. Rapid heating is cost-effective and power-saving.
7. The centre supporting rod for low- and high-power heaters is manufactured of M.S.
8. Resilient and durable.
9. Each component can be easily replaced.
